FLIRT UAV solutions combine the advantages of unmanned flying systems with high standards of piloted specialized aircrafts. The defining feature of our UAVs (unlike many others) is its ability to get series of well-aligned images even in a strong crosswind.

FLIRT features

own smart FlightPlanner for automatic mission creation
fully automatic flight from takeoff to landing
small size area for takeoff and landing
exceptional stability in flight gives clearest photos and data
wide range of altitudes and flight speeds
long flight endurance
distance mission control up to 20 km by radiolink
easily changeable payload
gyro stabilized camera gimbal
durable hull composite construction additionally protected with the system of dampers
doesn’t require any special tools and no electrical coupling involved at assembly process
automatic parachute landing system with emergency activation
easily transported in specially designed light and convenient cases.

Details

FLIRT Arrow

Arrow is a light-weight, hand-launchable model is specifically designed for aerial mapping, intelligence and video surveillance.

Use cases

security

emergencies

intelligence

Key advantages

Transporting, launch and controlling the mission itself can be easily carried out by a single person on foot
Stable operation even at high altitudes
Simultaneous video monitoring and aerial mapping with a high-resolution sensor during flight
Remotely controlled stabilized camera in the nose to get online HD video up to 30 km ahead
High-precision aerial orthophoto and DTM without additional field work due to precision GNSS L1/L2 PPK system onboard
Covert aerial reconnaissance and surveillance from high altitude in zero radio emission mode in conditions of active interference and GPS signal suppression

Technical characteristics

total system weight 8 kg
up to 150 minutes in flight
launch from hand or catapult
parachute landing
GSD from 0.5 cm
up to 150 km flight distance
up to 30 km HD video link
wind tolerance up to 10 m/s.

Payload applicable onboard

20,4 mp SONY UMC-R10c camera with changeable lens
Parrot SEQUOIA multispectral camera
FLIR VUE PRO/FLIR DUO PRO thermal sensor
HD quality pan/tilt/zoom nose video camera
NextVision thermal&optical PTZ camera
L1/L2 PPK GNSS

Details

FLIRT Cetus

Cetus is a highly-specialized aircraft designed for high precision aerial mapping of vast areas. Stabilized camera with full-frame sensor combined with great flight duration allows you to capture extremely big territories in single flight.

Use cases

Key advantages

High adaptability for different types of tasks thanks to interchangeable lens system
Gyro stabilized gimbal allows well-aligned series of pictures
Long distance flights even with strong wind conditions
High-precision aerial orthophoto and DTM without additional field work due to precision GNSS L1/L2 PPK system onboard
Simultaneous RGB and multispectral camera usage for agricultural monitoring.

Technical characteristics

total weight 9 kg
up to 3 hours in flight
up to 180 km flight distance
parachute landing + airbag protection system
GSD from 1 cm
up to 15 sq.km. with 5 cm GSD (60% side overlap)
wind tolerance up to 12 m/s

Payload applicable onboard

Full-frame up to 61 Mp RGB camera with interchangeable lens system
Optional multispectral camera
FLIR VUE PRO/FLIR DUO PRO thermal sensor
L1/L2 PPK GNSS

Details

FLIRT Iron

Iron is a unique model that combines speed and flight distances of fixed-wing systems with 360-degree overview for cameras, LIDAR and other big-size equipment, as in multicopters. Durable metal & fabric construction makes Iron almost indestructible.

Use cases

agricultural monitoring

LIDAR scanning

oblique camera capturing

Key advantages

various combinations of 360-degree capturing for different tasks
interchangeable camera lens
big open space for easy changeable payloads
extreme durability.

Technical characteristics

total weight 10 kg
catapult launch
parachute landing + airbag protection system
GSD from 0.5 cm
up to 60 min in flight
up to 60 km flight distance
up to 20 km HD video link
wind tolerance up to 12 m/c.

Payload applicable onboard

LIDAR
42 Mp RGB camera camera with interchangeable lens system
Multispectral camera
L1/L2 PPK GNSS
Oblique camera
Thermal camera 640×512.

Details

FLIRT Falcon

FLIRT Falcon was specially designed for professional industrial cameras and LIDAR scanners.

Use cases

LIDAR scanning

Key advantages

Fully automatic vertical takeoff and lending VTOL
Long flight time and range
High reliable
Easily transported in a small case

Technical characteristics

total weight 14 kg
up to 2.5 hours in flight
up to 150 km flight distance
wind tolerance up to 12 m/s
flight speed 18-28 m/s

Payload applicable onboard

Phase One full frame ultra-high resolution aerial cameras up to 150 MP
Riegle VUX-120 LiDAR
Full-frame up to 61 Mp RGB camera with interchangeable lens system
L1/L2 PPK GNSS
Multispectral camera
Thermal camera

Details

FLIRT Beetle

Lightweight, fully automatic and versatile Beetle delivers ultra-high detail and accuracy

Use cases

security

emergencies
